Product Features
Housing Design
Material: Aluminum Alloy
Protection Rating: IP67 waterproof and dustproof
Characteristics: Shock-resistant and collision-proof, robust and durable
Battery and Circuit Design
Overcharge and over-discharge protection
Input overvoltage/output overvoltage protection
Output overcurrent/short-circuit protection
Temperature protection
Battery: High-capacity Lithium Iron Phosphate (LFP) battery, stable performance, providing long-lasting power support
Built-in Protection Circuit
Output Circuit: Stable 12V output
Charging and Performance
Supports multi-voltage fast charging: 5V to 20V, compatible with QC protocol
Lifespan: Over 800 charge-discharge cycles
Advantages of Lithium Iron Phosphate (LFP) Batteries
High Safety：LFP batteries have excellent thermal stability, making them less likely to explode or catch fire. This ensures a safer and more reliable performance during use.
Long Lifespan：LFP batteries have a long cycle life, typically exceeding 2000 cycles. Compared to other battery types, they offer a longer service life and lower maintenance costs.
Environmentally Friendly：LFP batteries do not contain harmful substances and are environmentally friendly. They meet the modern demands for green energy development.
Product Parameter
| Product Model | MP-05B12W3 |
| Battery Type | Lithium Iron Phosphate |
| Battery Capacity | 6000mAh/12.8V 76.8Wh |
| Rated Capacity | 5250mAh/12V 0.5A 63Wh |
| Fast Charge (TYPE-C) | QC Protocol Fast Charge, 12V/1.5A (Approximately 2.5 hours to fully charge at 65W) |
| Input (TYPE-C) | 5V3A, 12V1.5A, 15V3A, 20V3A (Max 60W) |
| Output (DC5.5*2.1 Male Connector) | 12V1.0A (Max 12W) |
| Discharge Duration Calculation | Discharge Duration = 63Wh / (12V Load Current A) <br>Example: Load 0.25A, Discharge Duration = 63 / (12 x 0.25) x 90% ≈ 18 hours |
| Life Cycle | >800 cycles |
| Shock Resistance | 5G |
| Waterproof Rating | IP67 |
| Charging Temperature | 0℃ to +45℃ |
| Discharge Operating Temperature | -20℃ to +60℃ |
| Storage Temperature | -20℃ to +60℃ |
| Dimensions (mm) | 188mm x 88mm x 46.5mm (excluding tail wire) |
| Weight (g) | 1200g |
*This product information is for reference only! If there is any change, the actual product shall prevail, the final interpretation right belongs to our company!
