Product Features
IP69K (high-pressure water gun cleaning) Waterproof Rating
The patented design of the waterproof pressure reducing valve maintains the balance of air inside and outside the product and ensures the reliability of the waterproof seal.
Fish scale die-cast aluminum alloy shell and 2.0 thickness LED aluminum substrate maximize heat dissipation design to ensure stable electrical performance
Highly transparent anti-glare Lens and impact-resistant PMMA acrylic Lens with built-in reverse polarity and load pulse voltage protection
Wide operating voltage range DC10-30V
Comply with international electromagnetic compatibility (EMC) certification
Widely used in outdoor lighting such as engineering vehicles, special vehicles, off-road vehicles, etc.
Product Parameters
| Waterproof car LED auxiliary light | DF-L-A12B |
| power | 12W |
| Luminous flux | 800lm |
| lamp beads | 4 pcs 3W high power lamp beads |
| Operating Voltage | DC10~60V |
| Color Temperature | 6500K |
| Shell color | black |
| Light type | Low beam lights |
| Material | Die-cast aluminum shell, reinforced PC mask, PMMA Lens, aluminum alloy adjustment bracket |
| Warranty time | 3 years |
| Operating Temperature | -40℃~+60℃ |
| waterproof level | IP69K |
| Shockproof level | 5G |
| Weight | 700g |
| Size | 113X80X81(LengthXWidthXHeight) |
Product Applications
*This product information is for reference only! If there is any change, the actual product shall prevail, the final interpretation right belongs to our company!
