Product Features
Screen: 10.1-inch IPS screen with fast response speed, wide viewing angles, true colors, resolution of 1024RGBx600.,graphical menu for easy and quick operation.
DVR: real-time recording and playback functionality, supports 16-512GB TF cards(Standard 64G)
Video input: supports up to 6 CH (1080P/960P/720P/CVBS) of signal mixed input.
AI warning : AI Camera sends warning signals that trigger monitor built-in buzzer alarm and LED strobe light alerts on the monitor to remind the driver for safety alerts. ,
Video input: supports up to 6 video inputs and has real-time recording and playback functionality.
Full bonding process for screen: the protective glass panel, touch screen and Screen screen of the monitor adopt a space free fully bonded process structure,Eliminate specular reflection to ensure clear and transparent image Screen.
Brightness (600 cd/m2): automatically adjusts based on ambient light
Power and Protection: Operates within a wide voltage range of DC 8-32V. Features include pulse voltage protection against load nd voltage protection to prevent misuse and ensure longevity.
Product Parameters
| Model | MHD-1034MDJ-64G |
| Display | 10.1-inch IPS Screen |
| Resolution | 1024×(RGB)×600 |
| Video Input | 4 channels (1080P/960P/720P/CVBS) of signal mixed input |
| Viewing Angle (L/R, U/D) | L/R: 85/85; U/D: 85/85 |
| Contrast Ratio | 800:1 |
| Brightness (cd/㎡) | 600 |
| Response Time (ms) | 25 |
| Standard | PAL/NTSC (AUTO) |
| Video Recording Format | AVI |
| Video Recording Capacity | Supports 16-512GB TF cards(Standard 64G) |
| Recording Resolution | 1080P/720P/480P |
| Video Signal Input | Supports 1080P/720P/CVBS signals |
| Load Reject | DC24+174V/350ms |
| Operating Temperature | -20℃ to +70℃ |
| Storage Temperature | -30℃ to +80℃ |
| Input Power | DC11-32V |
| Dimensions (LxWxT) | 265 x 168 x 37 (mm) (excluding bracket) |
*This product information is for reference only! If there is any change, the actual product shall prevail, the final interpretation right belongs to our company!
