4-Channels AI intelligent 4G Dash Camera

  • Model : DF-V03-4G
  • Summarize : The product features H.265 and H.264 encoding and decoding to save storage space and transmission bandwidth. It supports 1-channel 1080p at 25fps along with 3 channels of 720p at 25fps. The system includes a built-in 1080p camera and allows for easy installation of three external HD cameras. It incorporates AI algorithms to support ADAS, DMS, and BSD functions, as well as GPS and Beidou dual-mode precise positioning. With support for 1 TF card and a super capacitor, it ensures the integrity of video files. It has a SIM card slot with a 4G module that can accommodate global frequency bands and offers WiFi hotspot capability. Users can preview video and configure parameters through a mobile app or client. Additionally, it supports 2-channel IO alarm inputs and 2-channel RS232. The built-in speaker and microphone enable voice intercom between the dash camera and the platform, along with TTS voice broadcasting. The device also features a one-key SOS emergency alarm, low-power sleep mode, and a special file system to enhance disk reading and writing efficiency, ensuring stable video recording.
  • More Info : Online Service

Product Features

H.265 & H.264 encoding and decoding,Save storage space and transmission flow;

Support 1-channel 1080p * 25fps + 3-channels 720p * 25fps;

Built in one 1080p camera and external three HD cameras for easy installation;;

Built in AI intelligent algorithm, which can support ADAS,DMS and BSD functions;

Built in GPS + Beidou dual-mode precise positioning;

Support 1 TF card,super capacitor double guarantees the integrity of video files;

Support 1 SIM card, 4G module can support global frequency band;

Support WiFi hotspot.

Support mobile app, client, preview video and parameter configuration;

Support 2CH IO alarm input and 2CH of RS232;

Built in speaker and microphone, Support voice intercom between dash camera and platform. TTS voice broadcast;

One key SOS emergency alarm; Support low-power sleep;

Special file system to improve disk reading and writing efficiency,More stable video recording;

Product Parameters

ITEM

Technical Specifications

CPU

Dual-Core processor@1.5GHz,Total coding resources 1080p*100fps

NPU@1.0TOPS neural network acceleration engine

Memory

2Gb DDR3

Video Input

Active Pixels: 1920×1080,1080×720; H.264&H.265 format

1-ch Built-in CMOS camera, Low illumination 0.01LUX

3-ch External camera, AHD 720P@25fps

Video Output

Not support,Support mobile APP preview and setting

Audio input / output

Built-in MIC and speaker, G.711a format

Video recording resolution

1080P/720P/D1*25fps,Simultaneous recording of sound and video.

G-Sensor

Built-in 3-axis acceleration

External interface

2-ch RS232, reserved for communication with peripherals

Alarm Input

2-ch sensor input,

Positioning module

Built-in GPS / Beidou Positioning Module

4G

built-in 4G module,TDD-LTE, FDD-LTE

WIFI

Built-in, 2.4G,802.11b/g/n,STA or AP mode

TF Card

Support 1 TF card, Support 16G/32G/64G/128G/256GB/512GB

USB

Micro USB interface

Upgrade

TF card and OTA

AI - ADAS

Lane departure, collision alarm, Distance detection, pedestrian detection etc

AI - DSM

Fatigue driving detection, Smoking, call mobile phone, Occlusion, Unsafe driving behavior habit detection

AI - BSD

Blind area detection

Input voltage

DC:+10V ~ +36V

Power consumption

Normal working state < 5W (without external equipment)

Power off protection

Super capacitor design, support abnormal power failure, ensure the integrity of video files

Working Temperature

-25℃ to +70℃

Working relative temperature

20% to 80%

Equipment size

138mm*85mm*45mm

Net weight

0.3kg


*This product information is for reference only! If there is any change, the actual product shall prevail, the final interpretation right belongs to our company!
